PI6C49CB01Q汽车CMOS时钟晶振缓冲器,PI6C49CB01Q2WEX,差分晶体振荡器,ECERA晶振

2022-07-06 16:28:54 康华尔电子

百利通亚陶晶振PI6C49CB01Q是一款1对1差分转LVCMOS/LVTTL转换器高性能缓冲器。PI6C49CB01Q汽车CMOS时钟晶振缓冲器,PI6C49CB01Q2WEX,差分晶体振荡器,ECERA晶振,输入非常灵活，可以接受LVPECL、LVDS、LVHSTL、SSTL和HCSL差分晶振。小型8引脚SOIC占位面积使该器件非常适合在电路板空间有限的应用中使用。汽车应用的低抖动时钟缓冲器ADAS和信息娱乐。

FD1940004 Diodes Incorporated SaRonix-eCera™ FD 19.44MHz ±50ppm -40°C ~ 85°C
FD2000046 Diodes Incorporated SaRonix-eCera™ FD 20MHz ±50ppm -20°C ~ 70°C
FD2000048 Diodes Incorporated SaRonix-eCera™ FD 20MHz ±50ppm -40°C ~ 85°C
FD2000049 Diodes Incorporated SaRonix-eCera™ FD 20MHz ±25ppm -20°C ~ 70°C
FD2400022 Diodes Incorporated SaRonix-eCera™ FD 24MHz ±50ppm -20°C ~ 70°C
FD2400023 Diodes Incorporated SaRonix-eCera™ FD 24MHz ±50ppm -40°C ~ 85°C
FD2400024 Diodes Incorporated SaRonix-eCera™ FD 24MHz ±25ppm -20°C ~ 70°C
FD2450018 Diodes Incorporated SaRonix-eCera™ FD 24.576MHz ±50ppm -20°C ~ 70°C
FD2450019 Diodes Incorporated SaRonix-eCera™ FD 24.576MHz ±25ppm -20°C ~ 70°C
FD2500049 Diodes Incorporated SaRonix-eCera™ FD 25MHz ±25ppm -20°C ~ 70°C
FD2500052 Diodes Incorporated SaRonix-eCera™ FD 25MHz ±50ppm -40°C ~ 85°C
FD2500054 Diodes Incorporated SaRonix-eCera™ FD 25MHz ±50ppm -40°C ~ 85°C
FD2500057 Diodes Incorporated SaRonix-eCera™ FD 25.0012MHz ±25ppm -20°C ~ 70°C
FD2500058 Diodes Incorporated SaRonix-eCera™ FD 25MHz ±50ppm -20°C ~ 70°C
FD2500061 Diodes Incorporated SaRonix-eCera™ FD 25MHz ±25ppm -20°C ~ 70°C
FD2600027 Diodes Incorporated SaRonix-eCera™ FD 26MHz ±50ppm -20°C ~ 70°C
FD2600028 Diodes Incorporated SaRonix-eCera™ FD 26MHz ±25ppm -20°C ~ 70°C
FD2600030 Diodes Incorporated SaRonix-eCera™ FD 26MHz ±50ppm -40°C ~ 85°C
FD2600031 Diodes Incorporated SaRonix-eCera™ FD 26MHz ±25ppm -20°C ~ 70°C
FD2660003 Diodes Incorporated SaRonix-eCera™ FD 26.66MHz ±25ppm -20°C ~ 70°C
FD2700033 Diodes Incorporated SaRonix-eCera™ FD 27MHz ±25ppm -20°C ~ 70°C
FD2700034 Diodes Incorporated SaRonix-eCera™ FD 27MHz ±50ppm -40°C ~ 85°C
FD2700035 Diodes Incorporated SaRonix-eCera™ FD 27MHz ±50ppm -20°C ~ 70°C
FD2700038 Diodes Incorporated SaRonix-eCera™ FD 27MHz ±50ppm -20°C ~ 70°C
FD2700043 Diodes Incorporated SaRonix-eCera™ FD 27MHz ±50ppm -20°C ~ 70°C
PI6C49CB01Q汽车CMOS时钟晶振缓冲器,PI6C49CB01Q2WEX,差分晶体振荡器,ECERA晶振

特征：
1路LVCMOS/LVTTL输出
差分CLK/nCLK 输入对
CLK/nCLK对可以接受以下差分输入电平：LVPECL、LVDS、LVHSTL、SSTL、HCSL
输出频率：360MHz 有源晶振
部件间偏移：500ps（最大值）
附加相位抖动，RMS：0.09ps（典型值），3.3V输出
完整的 3.3V和2.5V工作电源
-40°C至105°C环境工作温度
符合AEC-Q100标准 汽车晶振
汽车2级温度范围（-40至105℃）
汽车3级温度范围（-40至85℃）
完全无铅且完全符合 RoHS 标准
不含卤素和锑。“绿色”装置
PI6C49CB01Q 适用于需要特定变更控制的汽车应用，符合 AEC-Q100 标准，
具有 2 级 -40至105℃温度等级和 3 级 -40℃至85℃温度等级，支持 PPAP，并且
在 IATF16949:2016 认证设施中制造。
封装：8 引脚，SOIC (W)

FD2860005 Diodes Incorporated SaRonix-eCera™ FD 28.6363MHz ±50ppm -20°C ~ 70°C
FD2860006 Diodes Incorporated SaRonix-eCera™ FD 28.63636MHz ±50ppm -40°C ~ 85°C
FD3000014 Diodes Incorporated SaRonix-eCera™ FD 30MHz ±25ppm -20°C ~ 70°C
FD3000015 Diodes Incorporated SaRonix-eCera™ FD 30MHz ±50ppm -40°C ~ 85°C
FD3000016 Diodes Incorporated SaRonix-eCera™ FD 30MHz ±50ppm -20°C ~ 70°C
FD3120001 Diodes Incorporated SaRonix-eCera™ FD 31.25MHz ±25ppm -20°C ~ 70°C
FD3300021 Diodes Incorporated SaRonix-eCera™ FD 33MHz ±50ppm -20°C ~ 70°C
FD3300022 Diodes Incorporated SaRonix-eCera™ FD 33MHz ±25ppm -20°C ~ 70°C
FD3300023 Diodes Incorporated SaRonix-eCera™ FD 33MHz ±50ppm -40°C ~ 85°C
FD3330016 Diodes Incorporated SaRonix-eCera™ FD 33.333MHz ±25ppm -20°C ~ 70°C
FD3330017 Diodes Incorporated SaRonix-eCera™ FD 33.333MHz ±50ppm -40°C ~ 85°C
FD3330018 Diodes Incorporated SaRonix-eCera™ FD 33.3333MHz ±50ppm -20°C ~ 70°C
FD3330019 Diodes Incorporated SaRonix-eCera™ FD 33.3333MHz ±25ppm -20°C ~ 70°C
FD3330020 Diodes Incorporated SaRonix-eCera™ FD 33.3333MHz ±50ppm -40°C ~ 85°C
FD3330022 Diodes Incorporated SaRonix-eCera™ FD 33.333MHz ±50ppm -20°C ~ 70°C
FD3330024 Diodes Incorporated SaRonix-eCera™ FD 33.333333MHz ±25ppm -20°C ~ 70°C
FD3330026 Diodes Incorporated SaRonix-eCera™ FD 33.333MHz ±50ppm -40°C ~ 85°C
FD3430001 Diodes Incorporated SaRonix-eCera™ FD 34.368MHz ±25ppm -20°C ~ 70°C
FD3530003 Diodes Incorporated SaRonix-eCera™ FD 35.328MHz ±50ppm -20°C ~ 70°C
FD3530004 Diodes Incorporated SaRonix-eCera™ FD 35.328MHz ±25ppm -20°C ~ 70°C
FD3530005 Diodes Incorporated SaRonix-eCera™ FD 35.328MHz ±50ppm -40°C ~ 85°C
FD3600009 Diodes Incorporated SaRonix-eCera™ FD 36MHz ±25ppm -20°C ~ 70°C
FD3680001 Diodes Incorporated SaRonix-eCera™ FD 36.864MHz ±50ppm -20°C ~ 70°C
FD3680002 Diodes Incorporated SaRonix-eCera™ FD 36.864MHz ±25ppm -20°C ~ 70°C
FD3680003 Diodes Incorporated SaRonix-eCera™ FD 36.864MHz ±50ppm -40°C ~ 85°C
PI6C49CB01Q汽车CMOS时钟晶振缓冲器,PI6C49CB01Q2WEX,差分晶体振荡器,ECERA晶振

产品参数：
合规性（仅汽车支持PPAP）汽车电子晶振
功能 缓冲
输出数量 1
输出类型 LVCMOS/LVTTL
最大输出频率 250MHz
附加抖动 0.1ps
电源电压 2.5V-3.3V
输入类型 LVPECL、LVDS、LVHSTL、SSTL、HCSL
偏斜 250ps
环境或结温 -40℃至105℃

FD4000119 Diodes Incorporated SaRonix-eCera™ FD 40MHz ±50ppm -20°C ~ 70°C
FD4000120 Diodes Incorporated SaRonix-eCera™ FD 40MHz ±25ppm -20°C ~ 70°C
FD4000121 Diodes Incorporated SaRonix-eCera™ FD 40MHz ±50ppm -40°C ~ 85°C
FD4000123 Diodes Incorporated SaRonix-eCera™ FD 40MHz ±25ppm -20°C ~ 70°C
FD4100001 Diodes Incorporated SaRonix-eCera™ FD 41MHz ±50ppm -20°C ~ 70°C
FD4100002 Diodes Incorporated SaRonix-eCera™ FD 41MHz ±50ppm -20°C ~ 70°C
FD4400070 Diodes Incorporated SaRonix-eCera™ FD 41MHz ±50ppm -20°C ~ 70°C
FD4470001 Diodes Incorporated SaRonix-eCera™ FD 44.736MHz ±25ppm -20°C ~ 70°C
FD4800046 Diodes Incorporated SaRonix-eCera™ FD 48MHz ±50ppm -20°C ~ 70°C
FD4800047 Diodes Incorporated SaRonix-eCera™ FD 48MHz ±25ppm -20°C ~ 70°C
FD4800048 Diodes Incorporated SaRonix-eCera™ FD 48MHz ±50ppm -40°C ~ 85°C
FD4800050 Diodes Incorporated SaRonix-eCera™ FD 48MHz ±50ppm -20°C ~ 70°C
FD4910004 Diodes Incorporated SaRonix-eCera™ FD 49.152MHz ±25ppm -20°C ~ 70°C
FD5000032 Diodes Incorporated SaRonix-eCera™ FD 50MHz ±50ppm -20°C ~ 70°C
FD5000033 Diodes Incorporated SaRonix-eCera™ FD 50MHz ±25ppm -20°C ~ 70°C
FD5000034 Diodes Incorporated SaRonix-eCera™ FD 50MHz ±50ppm -40°C ~ 85°C
FD5000036 Diodes Incorporated SaRonix-eCera™ FD 50MHz ±50ppm -40°C ~ 85°C
FD5000037 Diodes Incorporated SaRonix-eCera™ FD 50MHz ±50ppm -20°C ~ 70°C
FD5000040 Diodes Incorporated SaRonix-eCera™ FD 50MHz ±50ppm -20°C ~ 70°C
FD5400017 Diodes Incorporated SaRonix-eCera™ FD 54MHz ±50ppm -40°C ~ 85°C
FD5670001 Diodes Incorporated SaRonix-eCera™ FD 56.75MHz ±50ppm -20°C ~ 70°C
FD6000016 Diodes Incorporated SaRonix-eCera™ FD 60MHz ±50ppm -20°C ~ 70°C
FD6250007 Diodes Incorporated SaRonix-eCera™ FD 62.5MHz ±50ppm -20°C ~ 70°C
FD6250008 Diodes Incorporated SaRonix-eCera™ FD 62.5MHz ±25ppm -20°C ~ 70°C
FD6250009 Diodes Incorporated SaRonix-eCera™ FD 62.5MHz ±50ppm -40°C ~ 85°C

PI6C49CB01Q汽车CMOS时钟晶振缓冲器,PI6C49CB01Q2WEX,差分晶体振荡器,ECERA晶振

PI6C49CB01Q/02Q/04xQ符合汽车标准 单端时钟缓冲器 已通过AECQ100级(105℃)和3级认证 (85℃)通过IATF16949认证 制造场所支持 PPAP文件。 随着汽车系统变得 更复杂的时钟 树也得到更多 复杂。为了服务于此， 多路输出时钟缓冲器 具有低抖动和低偏斜 必需的。 PI6C49CB01Q/02Q/04xQ 满足这一需求 一/二/四个CMOS/LVTTL 输出提供低偏斜、低 附加抖动和低功耗。 PI6C49CB01Q/02Q/ 04xQ 在SO-8中可用 包裹。

FD6250011 Diodes Incorporated SaRonix-eCera™ FD 62.5MHz ±50ppm -20°C ~ 70°C
FD6400006 Diodes Incorporated SaRonix-eCera™ FD 64MHz ±50ppm -20°C ~ 70°C
FD6400007 Diodes Incorporated SaRonix-eCera™ FD 64MHz ±25ppm -20°C ~ 70°C
FD6400008 Diodes Incorporated SaRonix-eCera™ FD 64MHz ±50ppm -40°C ~ 85°C
FD6600015 Diodes Incorporated SaRonix-eCera™ FD 66MHz ±25ppm -20°C ~ 70°C
FD6600016 Diodes Incorporated SaRonix-eCera™ FD 66MHz ±50ppm -40°C ~ 85°C
FD6600017 Diodes Incorporated SaRonix-eCera™ FD 66MHz ±50ppm -20°C ~ 70°C
FD6660016 Diodes Incorporated SaRonix-eCera™ FD 66.666MHz ±50ppm -20°C ~ 70°C
FD6660017 Diodes Incorporated SaRonix-eCera™ FD 66.666MHz ±25ppm -20°C ~ 70°C
FD6660018 Diodes Incorporated SaRonix-eCera™ FD 66.666MHz ±50ppm -40°C ~ 85°C
FD6660019 Diodes Incorporated SaRonix-eCera™ FD 66.6667MHz ±50ppm -20°C ~ 70°C
FD6660020 Diodes Incorporated SaRonix-eCera™ FD 66.6667MHz ±25ppm -20°C ~ 70°C
FD6660021 Diodes Incorporated SaRonix-eCera™ FD 66.6667MHz ±50ppm -40°C ~ 85°C
FD6660024 Diodes Incorporated SaRonix-eCera™ FD 66.667MHz ±25ppm -20°C ~ 70°C
FD6800001 Diodes Incorporated SaRonix-eCera™ FD 68MHz ±50ppm -40°C ~ 85°C
FD7420006 Diodes Incorporated SaRonix-eCera™ FD 74.25MHz ±25ppm -20°C ~ 70°C
FD7500010 Diodes Incorporated SaRonix-eCera™ FD 75MHz ±50ppm -20°C ~ 70°C
FD7500011 Diodes Incorporated SaRonix-eCera™ FD 75MHz ±25ppm -20°C ~ 70°C
FD7500013 Diodes Incorporated SaRonix-eCera™ FD 75MHz ±50ppm -40°C ~ 85°C
FD7770004 Diodes Incorporated SaRonix-eCera™ FD 77.76MHz ±50ppm -20°C ~ 70°C
FD7770005 Diodes Incorporated SaRonix-eCera™ FD 77.76MHz ±25ppm -20°C ~ 70°C
FD7770006 Diodes Incorporated SaRonix-eCera™ FD 77.76MHz ±50ppm -40°C ~ 85°C
FD7770007 Diodes Incorporated SaRonix-eCera™ FD 77.76MHz ±50ppm -20°C ~ 70°C
FD7770008 Diodes Incorporated SaRonix-eCera™ FD 77.76MHz ±25ppm -20°C ~ 70°C
FD7770009 Diodes Incorporated SaRonix-eCera™ FD 77.76MHz ±50ppm -40°C ~ 85°C

PI6C49CB01Q汽车CMOS时钟晶振缓冲器,PI6C49CB01Q2WEX,差分晶体振荡器,ECERA晶振

AEC-Q100 2级和3级通过IATF16949认证 认证制造场所: 汽车应用兼容，在-40℃范围内性能可靠至105℃和-40℃至85℃

低加性抖动(0.1psRMS)时钟 最小相位噪声增加系统定时裕量

低偏斜(25ps)时钟 所有输出时钟对齐并同步

低功耗 4路输出器件在1.5V时的总电源Idd低至5mA 降低系统功耗预算

小型8引脚SOIC封装 非常适合电路板空间有限的设计

应用程序：信息娱乐，ADAS，汽车网关

1

FDC500014 Diodes Incorporated SaRonix-eCera™ FD 125MHz ±50ppm -20°C ~ 70°C
FK0100001 Diodes Incorporated SaRonix-eCera™ FK 1MHz ±50ppm -20°C ~ 70°C
FK0100002 Diodes Incorporated SaRonix-eCera™ FK 1MHz ±50ppm -20°C ~ 70°C
FK0180004 Diodes Incorporated SaRonix-eCera™ FK 1.843MHz ±50ppm -20°C ~ 70°C
FK0180005 Diodes Incorporated SaRonix-eCera™ FK 1.843MHz ±25ppm -20°C ~ 70°C
FK0180006 Diodes Incorporated SaRonix-eCera™ FK 1.843MHz ±50ppm -40°C ~ 85°C
FK0200002 Diodes Incorporated SaRonix-eCera™ FK 2MHz ±50ppm -20°C ~ 70°C
FK0360002 Diodes Incorporated SaRonix-eCera™ FK 3.686MHz ±50ppm -20°C ~ 70°C
FK0360003 Diodes Incorporated SaRonix-eCera™ FK 3.686MHz ±25ppm -20°C ~ 70°C
FK0360004 Diodes Incorporated SaRonix-eCera™ FK 3.686MHz ±50ppm -40°C ~ 85°C
FK0400005 Diodes Incorporated SaRonix-eCera™ FK 4MHz ±25ppm -20°C ~ 70°C
FK0400007 Diodes Incorporated SaRonix-eCera™ FK 4MHz ±50ppm -40°C ~ 85°C
FK0500002 Diodes Incorporated SaRonix-eCera™ FK 5MHz ±50ppm -40°C ~ 85°C
FK0530001 Diodes Incorporated SaRonix-eCera™ FK 5.33MHz ±50ppm -40°C ~ 85°C
FK0610001 Diodes Incorporated SaRonix-eCera™ FK 6.14MHz ±25ppm -20°C ~ 70°C
FK0670001 Diodes Incorporated SaRonix-eCera™ FK 6.758MHz ±25ppm -20°C ~ 70°C
FK0800004 Diodes Incorporated SaRonix-eCera™ FK 8MHz ±50ppm -40°C ~ 85°C
FK0810001 Diodes Incorporated SaRonix-eCera™ FK 8.192MHz ±50ppm -20°C ~ 70°C
FK0810002 Diodes Incorporated SaRonix-eCera™ FK 8.192MHz ±25ppm -20°C ~ 70°C
FK0810003 Diodes Incorporated SaRonix-eCera™ FK 8.192MHz ±50ppm -40°C ~ 85°C
FK1000006 Diodes Incorporated SaRonix-eCera™ FK 10MHz ±50ppm -20°C ~ 70°C
FK1000007 Diodes Incorporated SaRonix-eCera™ FK 10MHz ±25ppm -20°C ~ 70°C
FK1000008 Diodes Incorporated SaRonix-eCera™ FK 10MHz ±50ppm -40°C ~ 85°C
FK1200010 Diodes Incorporated SaRonix-eCera™ FK 12MHz ±50ppm -20°C ~ 70°C
FK1200013 Diodes Incorporated SaRonix-eCera™ FK 12MHz ±25ppm -20°C ~ 70°C

PI6C49CB01Q汽车CMOS时钟晶振缓冲器,PI6C49CB01Q2WEX,差分晶体振荡器,ECERA晶振

零件号码 AEC-Q100等级 温度范围 包裹 磁带宽度 每卷数量
PI6C49CB01Q2WEX 2 -40 to 105ºC SO-8 12mm 2500
PI6C49CB01Q3WEX 3 -40 to 85ºC SO-8 12mm 2500
PI6C49CB02Q2WEX 2 -40 to 105ºC SO-8 12mm 2500
PI6C49CB02Q3WEX 3 -40 to 85ºC SO-8 12mm 2500
PI6C49CB04AQ2WEX 2 -40 to 105ºC SO-8 12mm 2500
PI6C49CB04AQ3WEX 3 -40 to 85ºC SO-8 12mm 2500
PI6C49CB04BQ2WEX 2 -40 to 105ºC SO-8 12mm 2500
PI6C49CB04BQ3WEX 3 -40 to 85ºC SO-8 12mm 2500
PI6C49CB04CQ2WEX 2 -40 to 105ºC SO-8 12mm 2500
PI6C49CB04CQ3WEX 3 -40 to 85ºC SO-8 12mm 2500
